PostPosted: Wed Oct 14, 2009 6:33 pm Reply with quoteBack to top

Code: APB (S4/A6)
Configuration: V6 engine with 90 degree V-angle and twin turbochargers.

Power: 250 hp (187 kW) at 5800 rpm
Torque: 258 lbs-ft (350 Nm) at 1850 rpm.
Max. engine speed: 6800 rpm.

Bore: 3.19 in. (81 mm)
Stroke: 3.40 in. (86.4 mm)
Displacement: 163 cu. in. (2671 cc)
Compression ratio: 9.3 : 1
Firing Order: 1 - 4 - 3 - 6 - 2 - 5

Engine Weight: Approx 440lbs (200kg)

Engine Management: Motronic ME7.1

Fuel: 91 AKI

_________________
SOLD: 2003 RS6 Mugello Blue Avant | KW v3 | West Tuned | Hotchkis ARBs | MTM Bimotos | Milltek | Black Optics | Solar Roof | HUD

Please vote for AudiSRS: HERE!
View user's profileSend private message
bluebrakes
Veteran



Joined: 26 Sep 2008
Posts: 6872


PostPosted: Wed Oct 14, 2009 6:36 pm Reply with quoteBack to top

and what a wonderful engine it is.
View user's profileSend private message
GardinerG
Skilled


Car: Audi RS6 Avant
Power: 510Bhp

Joined: 21 Apr 2008
Posts: 1640

Location: Fleet, Hampshire

PostPosted: Wed Oct 14, 2009 6:40 pm Reply with quoteBack to top

Depending on if you believe the figures in the Audi tech books the V6 is lighter than the Alumisil alloy V8...

_________________
SOLD: 2003 RS6 Mugello Blue Avant | KW v3 | West Tuned | Hotchkis ARBs | MTM Bimotos | Milltek | Black Optics | Solar Roof | HUD

Please vote for AudiSRS: HERE!
View user's profileSend private message
GardinerG
Skilled


Car: Audi RS6 Avant
Power: 510Bhp

Joined: 21 Apr 2008
Posts: 1640

Location: Fleet, Hampshire

PostPosted: Thu Oct 15, 2009 8:32 pm Reply with quoteBack to top

FYI, the above data is from the US spec S4, if you didn't already know.

_________________
SOLD: 2003 RS6 Mugello Blue Avant | KW v3 | West Tuned | Hotchkis ARBs | MTM Bimotos | Milltek | Black Optics | Solar Roof | HUD

Please vote for AudiSRS: HERE!
View user's profileSend private message
danregs
knowledgeable


Car: S4 Quattro Avant
Power: 265
Torque: 295

Joined: 03 Jun 2009
Posts: 610

Location: Devon

PostPosted: Fri Oct 16, 2009 4:51 pm Reply with quoteBack to top

yeah, isn't the UK S4 spec APB 265PS/261bhp, not 250hp?

_________________
Dan

View user's profileSend private message
danregs
knowledgeable


Car: S4 Quattro Avant
Power: 265
Torque: 295

Joined: 03 Jun 2009
Posts: 610

Location: Devon

PostPosted: Fri Oct 16, 2009 8:51 pm Reply with quoteBack to top

or are all UK spec ones AGB??

_________________
Dan

View user's profileSend private message
GardinerG
Skilled


Car: Audi RS6 Avant
Power: 510Bhp

Joined: 21 Apr 2008
Posts: 1640

Location: Fleet, Hampshire

PostPosted: Fri Oct 16, 2009 9:17 pm Reply with quoteBack to top

Yes, the US S4 was 250bhp, whereas the european was 261bhp, not sure about the engine code though.

_________________
SOLD: 2003 RS6 Mugello Blue Avant | KW v3 | West Tuned | Hotchkis ARBs | MTM Bimotos | Milltek | Black Optics | Solar Roof | HUD

Please vote for AudiSRS: HERE!
View user's profileSend private message
danregs
knowledgeable


Car: S4 Quattro Avant
Power: 265
Torque: 295

Joined: 03 Jun 2009
Posts: 610

Location: Devon

PostPosted: Fri Oct 16, 2009 9:25 pm Reply with quoteBack to top

ah, ok, cheers!

i think the euro S4 was AGB, but I could be wrong!

i know mine is an AGB

_________________
Dan

View user's profileSend private message
Nez
Expert


Car: Audi S4 B8 3.0 TFSI
Power: 492 PS
Torque: 603 Nm

Joined: 11 Sep 2009
Posts: 5384

Location: London

PostPosted: Sat Oct 17, 2009 3:26 pm Reply with quoteBack to top

B5 powertrain

The powertrain detail of the B5 S4 features a 2.7 litre twin-turbo ('biturbo') 90 third-generation V6 engine (parts code prefix: 078, identification codes: AGB, AZB). Detail of the powerplant includes a cast iron cylinder block with two lightweight aluminium alloy cylinder heads.

The valvetrain includes 30 valves (five valves per cylinder) twin hybrid-driven (timing belt and chain) double overhead camshafts and variable valve timing for the inlet valves. The charged intake air is cooled with the aid of two side-mounted intercoolers (SMICs).

It displaces 2,671 cubic centimetres (163.0 cu in), and is DIN rated to produce a motive power output of 195 kilowatts (265 PS; 261 bhp), and generates 400 newton metres (295 ftlbf) of torque. Engine management was by way of a Bosch Motronic ME 7.1 (7.0 in North America) engine control unit (ECU), and helped it meet the EU-3D emissions standard. For a short time scale (08/98-12/9 in the North American market, the engine was slightly detuned to meet US emissions regulations, output was reduced to 187 kW (254 PS; 251 bhp) and 258 ftlb (350 Nm) (identification code: APB).

_________________
AUDI S4 B8 3.0 TFSI MRC tuning stage 2, Milltek Sport cat-back system and Bilstein Pro B12 Suspension
View user's profileSend private messageVisit poster's website
MilkybarKid
Experienced


Car: Mk2 Golf
Power: 537hp
Torque: 560lb.ft

Joined: 08 Sep 2008
Posts: 2849

Location: Under the car...

PostPosted: Sat Nov 07, 2009 5:36 pm Reply with quoteBack to top

Anyone know the original compression ratio of the RS4 engine or is it the same as standard?
View user's profileSend private messageMSN Messenger
okkim
Skilled


Car: WB S4 Avant + sedan
Engine code: AGB

Joined: 11 Jun 2008
Posts: 1757

Location: Finland

PostPosted: Tue Sep 21, 2010 2:37 pm Reply with quoteBack to top

It is 9.0:1. S4 has 9.3:1.

_________________
www.valitalo.org
View user's profileSend private messageSend e-mailVisit poster's website
piemachine
Learning


Car: S4 B5
Power: 265

Joined: 19 Jan 2012
Posts: 65

Location: Sheffield

PostPosted: Mon Dec 17, 2012 6:18 pm Reply with quoteBack to top

Hi

Can anyone reliably tell me the block deck height, failing that, con-rod length and piston pin to crown dimension?

Regards.
View user's profileSend private message
Jism
Learning


Car: 2001 RS4 B5

Joined: 29 Oct 2016
Posts: 62

Location: Holland

PostPosted: Mon Oct 31, 2016 7:24 am Reply with quoteBack to top

GardinerG wrote:
Yes, the US S4 was 250bhp, whereas the european was 261bhp, not sure about the engine code though.


I think because of emissions. USA is much harder on that then europe, however with these VW diesel scandals it wont take much time before new rules are applied.

The VR6 12V in Europe had more output then the USA VR6 12v if i'm not mistaken as well.
